| Nombor Bahagian | LT101MB02000 |
| Jenama | JDI |
| Saiz | 10.1 |
| Permohonan | PAD |
| Resolusi | 1920×1200 |
| Komposisi | LCM |
| Kecerahan | 340 |
| CR | 500:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | MIPI |
| jenama panel | JDI |
| model panel | LT101MB02000 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 10.1 inch |
| resolusi | 1920(RGB)×1200 , WUXGA |
| mod paparan | Normally Black, Transmissive |
| kawasan aktif | 217.44×135.9 mm |
| garis besar | 228.1×147.5×3.89 mm |
| permukaan | Antiglare |
| kecerahan | 340 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193160% |
| masa tindak balas | 60/40 (Max.)(Tr/Td) |
| sudut pandangan | 70/70/70/70 (Min.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 5 stringsWLEDWithout Driver |
| antara muka isyarat | MIPI (4 data lanes), 40 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | PAD |
