| Nombor Bahagian | NL8048BC24-09D |
| Jenama | NLT |
| Saiz | 9.0 |
| Permohonan | IA |
| Resolusi | 800×480 |
| Komposisi | LCM |
| Kecerahan | 400 |
| CR | 800:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | NEC |
| model panel | NL8048BC24-09D |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 9.0 inch |
| resolusi | 800(RGB)×480 , WVGA |
| mod paparan | UA-SFT, Normally Black, Transmissive |
| kawasan aktif | 196.8×118.08 mm |
| garis besar | 220.5×136.5×8.7 mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 400 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) |
| warna paparan | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193160% |
| masa tindak balas | 10/15 (Typ.)(Tr/Td) |
| sudut pandangan | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 3 stringsWLEDWithout Driver |
| antara muka isyarat | LVDS (1 ch, 6/8-bit), 20 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | IA |
