| Nombor Bahagian | HE101NA-02C |
| Jenama | Innolux |
| Saiz | 10.1 |
| Permohonan | PAD |
| Resolusi | 1280×800 |
| Komposisi | CELL |
| Kecerahan | 0 |
| CR | 700:1 |
| Warna | 16.7M |
| Lampu latar | No B/L |
| Antara muka | TTL |
| jenama panel | CHIMEI INNOLUX |
| model panel | HE101NA-02C |
| jenis panel | a-Si TFT-LCD , CELL |
| saiz panel | 10.1 inch |
| resolusi | 1280(RGB)×800 , WXGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 216.96×135.6 mm |
| garis besar | 224.21×145×1.43 mm |
| permukaan | Glare (Haze 0%) |
| kedalaman kaca | 0.50+0.50 mm |
| nisbah kontras | 700:1 (Typ.) |
| warna paparan | 16.7M (8-bit) |
| masa tindak balas | 10/20 (Typ.)(Tr/Td) |
| sudut pandangan | 75/70/75/75 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| antara muka isyarat | Parallel RGB (1 ch, 8-bit), 40 pins |
| voltan masukan | 3.3/11.0/20.0/-6.8V (Typ.)(DVDD/AVDD/VGH/VGL) |
| permohonan | PAD |
