| Nombor Bahagian | B080XAT01.1 |
| Jenama | AUO |
| Saiz | 7.9 |
| Permohonan | PAD |
| Resolusi | 768×1024 |
| Komposisi | Assembly |
| Kecerahan | 230 |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | MIPI |
| jenama panel | AUO |
| model panel | B080XAT01.1 |
| jenis panel | a-Si TFT-LCD , Assembly |
| saiz panel | 7.9 inch |
| resolusi | 768(RGB)×1024 , XGA |
| kawasan aktif | 119.808×159.744 mm |
| garis besar | 142×205×6.1 mm |
| permukaan | |
| kecerahan | 230 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Typ.) |
| warna paparan | 262K (6-bit), CIE193150% |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| antara muka isyarat | MIPI (4 data lanes), 35 pins |
| voltan masukan | 3.7V (Typ.) |
| permohonan | PAD |
