| Nombor Bahagian | EL640.480-AA1 |
| Jenama | Lumineq |
| Saiz | 10.4 |
| Permohonan | IA |
| Resolusi | 640×480 |
| Komposisi | EL |
| Kecerahan | 20 |
| CR | 10:1 |
| Warna | 8 |
| Lampu latar | self |
| Antara muka | Parallel Data |
| jenama panel | Lumineq |
| model panel | EL640.480-AA1 |
| jenis panel | EL , EL |
| saiz panel | 10.4 inch |
| resolusi | 640(RG)×480 , VGA |
| kawasan aktif | 211.1×158.3 mm |
| garis besar | 263×205 mm |
| permukaan | |
| kecerahan | 20 cd/m² (Typ.) |
| nisbah kontras | 10 : 1 (Typ.) |
| warna paparan | 8 (3-bit) |
| sudut pandangan | 70/70/70/70 (Typ.)(L/R/U/D) |
| antara muka isyarat | Parallel Data (4-bit), 40 pins |
| voltan masukan | 5.0/12.0V (Typ.)(VCC1/VCC2) |
| permohonan | IA |
