EL640.400-CB1 FRA

EL640.400-CB1 FRA
EL640.400-CB1 FRA thumb
Jenama
Lumineq
Saiz
9.1
Permohonan
IA
Resolusi
640×400
Komposisi
EL
Kecerahan
50
CR
Warna
Mono(Yellow)
Lampu latar
self
Antara muka
In Stock
60
Spesifikasi

Nombor Bahagian EL640.400-CB1 FRA
JenamaLumineq
Saiz9.1
PermohonanIA
Resolusi640×400
KomposisiEL
Kecerahan50
CR
WarnaMono(Yellow)
Lampu latarself
Antara muka
jenama panelLumineq
model panelEL640.400-CB1 FRA
jenis panel EL , EL
saiz panel9.1 inch
resolusi640×400
kawasan aktif195×121.8 mm
garis besar225×147 mm
permukaan
kecerahan50 cd/m² (Typ.)
nisbah kontras
warna paparanMono(Yellow) (1-bit)
sudut pandangan89/89/89/89 (Typ.)(L/R/U/D)
kekerapan70Hz
voltan masukan5/12V (Typ.)(VCC1/VCC2)
permohonanIA
