| Nombor Bahagian | LM081HB1T01 |
| Jenama | SHARP |
| Saiz | 8.1 |
| Permohonan | IA |
| Resolusi | 640×240 |
| Komposisi | LCM |
| Kecerahan | 150 |
| CR | 8:1 |
| Warna | Monochrome |
| Lampu latar | CCFL |
| Antara muka | Parallel Data |
| jenama panel | SHARP |
| model panel | LM081HB1T01 |
| jenis panel | FSTN-LCD , LCM |
| saiz panel | 8.1 inch |
| resolusi | 640×240 , HVGA |
| mod paparan | STN, Black/White (Negative) |
| kawasan aktif | 191.99×71.99 mm |
| garis besar | 249×99.4 mm |
| permukaan | |
| kecerahan | 150 cd/m² (Typ.) |
| nisbah kontras | 8 : 1 (Typ.) |
| warna paparan | Monochrome |
| masa tindak balas | 430/170 (Typ.)(Tr/Td) |
| sudut pandangan | 30/30/20/35 (Typ.)(CR≥2)(L/R/U/D) |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | Parallel Data (4-bit), 15 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | IA |
