AM-640480G2TNQW-31H-F

AM-640480G2TNQW-31H-F
AM-640480G2TNQW-31H-F
AM-640480G2TNQW-31H-F thumb AM-640480G2TNQW-31H-F thumb
Jenama
AMPIRE
Saiz
5.7
Permohonan
IA
Resolusi
640×480
Komposisi
LCM
Kecerahan
500
CR
250:1
Warna
262K
Lampu latar
WLED
Antara muka
TTL
In Stock
60
Spesifikasi

Nombor Bahagian AM-640480G2TNQW-31H-F
JenamaAMPIRE
Saiz5.7
PermohonanIA
Resolusi640×480
KomposisiLCM
Kecerahan500
CR250:1
Warna262K
Lampu latarWLED
Antara mukaTTL
jenama panelAMPIRE
model panelAM-640480G2TNQW-31H-F
jenis panel a-Si TFT-LCD , LCM
saiz panel5.7 inch
resolusi640(RGB)×480 , VGA
mod paparanTN, Normally White, Transmissive
kawasan aktif115.2×86.4 mm
garis besar127×98.43×6.9 mm
permukaanAntiglare, Hard coating (3H)
kecerahan500 cd/m² (Typ.)
nisbah kontras250:1 (Typ.)
warna paparan262K (6-bit)
masa tindak balas50 (Typ.)(Tr+Td)
sudut pandangan70/70/50/50 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampuWLEDEmbedded (LED Driver)
antara muka isyaratParallel RGB (1 ch, 6-bit), 40 pins
voltan masukan3.3/5.0V (Typ.)(VCC/VDD)
permohonanIA
Model Keluarga
AM-640480G2TNQW-00H-F AMPIRE 5.7 640×480
AM-640480G2TNQW-31H AMPIRE 5.7 640×480
AM-640480G2TNQW-31H-F AMPIRE 5.7 640×480
AM-640480G2TNQW-T01H-A AMPIRE 5.7 640×480
AM-640480G4TNQW-A0H AMPIRE 5.7 640×480
AM-640480G4TNQW-T01H AMPIRE 5.7 640×480
AM-640480GFTNQW-T01H-L AMPIRE 5.7 640×480
AM-640480GJTNQW-TA0H AMPIRE 5.7 640×480
EL320.240.36 HB NE PLANAR 5.7 320×240
KG057QV1CA-G000 Kyocera 5.7 320×240
