| Nombor Bahagian | TX17D01VM2EAB |
| Jenama | KOE |
| Saiz | 6.5 |
| Permohonan | IA |
| Resolusi | 640×480 |
| Komposisi | LCM |
| Kecerahan | 1000 |
| CR | 600:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | HITACHI |
| model panel | TX17D01VM2EAB |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 6.5 inch |
| resolusi | 640(RGB)×480 , VGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 132.48×99.36 mm |
| garis besar | 153×118 mm |
| permukaan | Glare (Haze 0%), Antireflection |
| kecerahan | 1000 cd/m² (Typ.) |
| nisbah kontras | 600:1 (Typ.) |
| warna paparan | 262K (6-bit), CIE193150% |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| sudut pandangan | 80/80/60/80 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 3S4PWLEDEmbedded (LED Driver) |
| antara muka isyarat | CMOS (1 ch, 6-bit), 31 pins |
| voltan masukan | 3.3V (Typ.)(VDD) |
| permohonan | IA |
