| Nombor Bahagian | DMC-16117A |
| Jenama | Kyocera |
| Saiz | 2.4 |
| Permohonan | |
| Resolusi | 16×1 |
| Komposisi | LCM |
| Kecerahan | |
| CR | |
| Warna | Monochrome |
| Lampu latar | No B/L |
| Antara muka | CPU |
| jenama panel | OPTREX |
| model panel | DMC-16117A |
| jenis panel | TN-LCD , LCM |
| saiz panel | 2.4 inch |
| format paparan | 16 characters × 1 lines |
| mod paparan | TN, Reflective |
| paparan fon | 5×8 dots |
| saiz watak | 3.2×5.95 mm |
| nada watak | 3.75×5.95 mm |
| kawasan aktif | 59.4×5.95 mm |
| kawasan bezel | 64.5×13.0 mm |
| garis besar | 80×36×10 mm |
| kecerahan | |
| nisbah kontras | 3.5:1 (Typ.)(Reflective) |
| warna paparan | Monochrome |
| masa tindak balas | 180/130 (Typ.)(Tr/Td) |
| jenis lampu | No B/L |
| antara muka isyarat | 8-bit parallel, 14 pins |
| voltan masukan | 5.0V (Typ.) |
