| Nombor Bahagian | LS024Q8DD92 |
| Jenama | SHARP |
| Saiz | 2.4 |
| Permohonan | |
| Resolusi | 240×320 |
| Komposisi | CELL |
| Kecerahan | 0 |
| CR | 100:1 |
| Warna | 65K/262K |
| Lampu latar | No B/L |
| Antara muka | TTL |
| jenama panel | SHARP |
| model panel | LS024Q8DD92 |
| jenis panel | CG-Silicon , CELL |
| saiz panel | 2.4 inch |
| resolusi | 240(RGB)×320 , QVGA |
| mod paparan | TN, Normally White, Transflective |
| kawasan aktif | 36.72×48.96 mm |
| garis besar | 41.2×58 mm |
| permukaan | Hard coating (3H) |
| kedalaman kaca | 0.50+0.50 mm |
| nisbah kontras | 100:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| warna paparan | 65K/262K |
| masa tindak balas | 13/35 (Typ.)(Tr/Td) |
| sudut pandangan | 45/45/35/45 (Typ.)(CR≥3)(L/R/U/D) |
| ic pemandu | Built-in uPD161831 |
| antara muka isyarat | Parallel RGB (1 ch, 6-bit), 60 pins |
| voltan masukan | 3.0/3.0V (Typ.)(VCC/VDC) |
