| Nombor Bahagian | DMC-16230NY-LY-EEE-EGN |
| Jenama | Kyocera |
| Saiz | 3.8 |
| Permohonan | |
| Resolusi | 16×2 |
| Komposisi | LCM |
| Kecerahan | |
| CR | 12:1 |
| Warna | Monochrome |
| Lampu latar | YG-LED |
| Antara muka | CPU |
| jenama panel | Kyocera |
| model panel | DMC-16230NY-LY-EEE-EGN |
| jenis panel | STN-LCD , LCM |
| saiz panel | 3.8 inch |
| format paparan | 16 characters × 2 lines |
| mod paparan | STN, Yellow/Green (Positive), Transmissive |
| paparan fon | 5×7 dots + cursor |
| saiz watak | 4.84×8.06 mm |
| nada watak | 6.00×10.0 mm |
| kawasan aktif | 94.84×20 mm |
| kawasan bezel | 99.0×24.0 mm |
| garis besar | 122×44×14.6 mm |
| kecerahan | |
| nisbah kontras | 12:1 (Typ.) |
| warna paparan | Monochrome |
| masa tindak balas | 130/180 (Typ.)(Tr/Td) |
| jenis lampu | 2S24PYG-LEDWithout Driver |
| antara muka isyarat | 8-bit parallel, 14 pins |
| voltan masukan | 5.0V (Typ.) |
