| Nombor Bahagian | DLC1010AZG-1 |
| Jenama | Other |
| Saiz | 10.1 |
| Permohonan | CNS |
| Resolusi | 1024×600 |
| Komposisi | LCM |
| Kecerahan | 1000 |
| CR | 250:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | DLC |
| model panel | DLC1010AZG-1 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 10.1 inch |
| resolusi | 1024(RGB)×600 , WSVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 222.72×125.28 mm |
| garis besar | 235×149.52 mm |
| permukaan | |
| kecerahan | 1000 cd/m² (Typ.) |
| nisbah kontras | 250:1 (Typ.) |
| warna paparan | 16.7M (8-bit) |
| masa tindak balas | |
| sudut pandangan | 85/85/85/60 (Typ.)(CR≥10)(L/R/U/D) |
| jenis lampu | 3S16PWLEDWithout Driver |
| antara muka isyarat | LVDS (1 ch, 8-bit), 30 pins |
| voltan masukan | 3.3/10.5V (Typ.)(VCC/AVDD) |
| permohonan | CNS |
