| Nombor Bahagian | YX035CM31 |
| Jenama | |
| Saiz | 3.5 |
| Permohonan | HHP |
| Resolusi | 320×240 |
| Komposisi | LCM |
| Kecerahan | 800 |
| CR | 400:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | Parallel/Serial |
| jenama panel | |
| model panel | YX035CM31 1 Compatible model |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 3.5 inch |
| resolusi | 320(RGB)×240 , QVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 70.08×52.56 mm |
| garis besar | 76.9×63.9 mm |
| permukaan | Antiglare (Haze 20%) |
| kecerahan | 800 cd/m² (Typ.) |
| nisbah kontras | 400:1 (Typ.) |
| warna paparan | 16.7M (8-bit) |
| masa tindak balas | 10/15 (Typ.)(Tr/Td) |
| sudut pandangan | 60/60/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 5S2PWLEDWithout Driver |
| antara muka isyarat | Digital RGB (8/24-bit) + SPI, CCIR601/656, 54 pins |
| voltan masukan | 3.3/13.9/13.6V (Typ.)(VCC/VGH/VGL) |
| permohonan | HHP |
| 35QVW1T | SII | 3.5 | 320×240 |
| H347QVN02.0 | AUO | 3.5 | 320×480 |
| LMS350GF03-001 | Samsung | 3.5 | 320×240 |
| LTV350QV-F07 | Samsung | 3.5 | 320×240 |
| PD035QX1 | E Ink | 3.5 | 240×320 |
| PJ035MA-02A | Innolux | 3.5 | 320×480 |
| PT035TN23 V.3 | Innolux | 3.5 | 320×240 |
| TM035KBH02 | Tianma | 3.5 | 320×240 |
| TM035KDH03-79 | Tianma | 3.5 | 320×240 |
| YX035CM31 | 3.5 | 320×240 |
