Innolux PT035TN23 V.3 lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com
LookLCD LookLCD


PT035TN23 V.3

PT035TN23 V.3
PT035TN23 V.3
PT035TN23 V.3
PT035TN23 V.3 thumb PT035TN23 V.3 thumb PT035TN23 V.3 thumb
Jenama
Innolux
Saiz
3.5
Permohonan
DSC
Resolusi
320×240
Komposisi
LCM
Kecerahan
CR
500:1
Warna
262K
Lampu latar
WLED
Antara muka
In Stock
13823
Spesifikasi

Nombor Bahagian PT035TN23 V.3
JenamaInnolux
Saiz3.5
PermohonanDSC
Resolusi320×240
KomposisiLCM
Kecerahan
CR500:1
Warna262K
Lampu latarWLED
Antara muka
jenama panelCHIMEI INNOLUX
model panelPT035TN23 V.3
jenis panel a-Si TFT-LCD , LCM
saiz panel3.5 inch
resolusi320(RGB)×240 , QVGA
mod paparanTN, Normally White, Transmissive
kawasan aktif70.08×52.56 mm
permukaanHard coating
kecerahan
nisbah kontras500:1 (Typ.)
warna paparan262K (6-bit)
masa tindak balas9/16 (Typ.)(Tr/Td)
sudut pandangan65/65/50/65 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampuWLED
permohonanDSC
