| Nombor Bahagian | WG12232A-YYH-N#A |
| Jenama | Winstar |
| Saiz | 2.2 |
| Permohonan | Industrial Instrumen |
| Resolusi | 122×32 |
| Komposisi | LCM, STN-LCD |
| Kecerahan | |
| CR | 3:1 |
| Warna | Monochrome |
| Lampu latar | YG-LED |
| Antara muka | |
| pengilang | Winstar |
| nama model | WG12232A-YYH-N#A |
| saiz skrin | 2.2 inch |
| jenis skrin | LCM, STN-LCD |
| nombor piksel | 122×32 57PPI |
| susunan | Rectangle |
| kawasan aktif (mm) | 53.64 × 15.64 (H×V) |
| garis besar (mm) | 84 × 44 × 13.7 (H×V×D) |
| kawasan bezel (mm) | 60.0 × 18.0 (H×V) |
| rawatan | - |
| kecerahan | - |
| nisbah kontras | 3 : 1 (Typ.) (TM) |
| sudut pandangan | 30/30/20/40 (Max.)(CR≥2) |
| tindak balas | 200/200 (Typ.)(Tr/Td) ms |
| pandangan yang baik di | 6 o'clock |
| mod kerja | STN, Yellow/Green (Positive), Transflective |
| kedalaman warna | Monochrome |
| lampu latar | YG-LED , 50K hours , No Driver |
| jisim | - |
| digunakan untuk | Industrial Instruments & Meters |
| kadar segar semula | - |
| skrin sentuh | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
