| Nombor Bahagian | WEO001602GG |
| Jenama | Winstar |
| Saiz | 2.3 |
| Permohonan | Instruments & Me |
| Resolusi | 16×27 |
| Komposisi | PM-OLED, OLED |
| Kecerahan | |
| CR | 2000:1 |
| Warna | Mono(Green) |
| Lampu latar | self |
| Antara muka | 8-bit |
| jenama panel | Winstar |
| model panel | WEO001602GG |
| saiz panel | 2.3" |
| jenis panel | PM-OLED, OLED |
| format paparan | 16 characters × 2 lines, 7PPI |
| format fon | 5×8 dots |
| saiz watak | 2.97×5.57(W×H) mm |
| nada watak | 3.55×5.95(W×H) mm |
| kawasan paparan | 56.22(W)×11.52(H) mm |
| pembukaan bezel | 58.22(W)×13.52(H) mm |
| saiz garis besar | 79(W)×44(H) ×9.67(D) mm |
| permukaan | - |
| kecerahan | - |
| nisbah kontras | 2000:1 (Typ.) (TM) |
| sudut pandangan | 88/88/88/88 |
| mod paparan | - |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 0.01 (Typ.) |
| warna paparan | Mono(Green) |
| jenis lampu | self |
| kekerapan | - |
| skrin sentuh | Without |
| ic pemandu | COGBuilt-in SSD1311M1Z |
| berat panel | - |
| permohonan | Instruments & Meters |
| antara muka isyarat | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 16 pins Pad |
| voltan masukan | 3.3/5.0V (Typ.)(VDD) |
