| Nombor Bahagian | AMC162B |
| Jenama | Other |
| Saiz | 2.3 |
| Permohonan | |
| Resolusi | 16×2 |
| Komposisi | LCM |
| Kecerahan | |
| CR | |
| Warna | Monochrome |
| Lampu latar | YG-LED |
| Antara muka | CPU |
| jenama panel | Amson |
| model panel | AMC162B |
| jenis panel | STN-LCD , LCM |
| saiz panel | 2.3 inch |
| format paparan | 16 characters × 2 lines |
| mod paparan | STN, Yellow/Green (Positive) |
| paparan fon | 5×7 dots + cursor |
| saiz watak | 2.96×5.56 mm |
| nada watak | 3.55×5.94 mm |
| kawasan aktif | 56.21×11.5 mm |
| kawasan bezel | 64.0×16.0 mm |
| garis besar | 85×30×12.7 mm |
| kecerahan | |
| nisbah kontras | |
| warna paparan | Monochrome |
| masa tindak balas | |
| jenis lampu | YG-LED |
| antara muka isyarat | 8-bit parallel, 14 pins |
| voltan masukan | 5.0V (Typ.) |
