| Nombor Bahagian | TM023KDH60 |
| Jenama | Tianma |
| Saiz | 2.3 |
| Permohonan | MPH |
| Resolusi | 320×240 |
| Komposisi | LCM |
| Kecerahan | |
| CR | |
| Warna | 65K/262K |
| Lampu latar | WLED |
| Antara muka | |
| jenama panel | TIANMA |
| model panel | TM023KDH60 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 2.3 inch |
| resolusi | 320(RGB)×240 , QVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 46.752×35.064 mm |
| permukaan | |
| kecerahan | |
| nisbah kontras | |
| warna paparan | 65K/262K , CIE193150% |
| masa tindak balas | 20 (Typ.)(Tr+Td) |
| sudut pandangan | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | WLED |
| permohonan | MPH |
