| Nombor Bahagian | AL1602B |
| Jenama | Other |
| Saiz | 2.3 |
| Permohonan | |
| Resolusi | 16×2 |
| Komposisi | OLED |
| Kecerahan | |
| CR | |
| Warna | Mono(White) |
| Lampu latar | self |
| Antara muka | CPU |
| jenama panel | Amson |
| model panel | AL1602B |
| jenis panel | PM-OLED , OLED |
| saiz panel | 2.3 inch |
| format paparan | 16 characters × 2 lines |
| paparan fon | 5×7 dots + cursor |
| saiz watak | 2.97×5.57 mm |
| nada watak | 3.55×5.95 mm |
| kawasan aktif | 56.22×11.52 mm |
| kawasan bezel | 58.22×13.25 mm |
| garis besar | 80×36×9.7 mm |
| kecerahan | |
| nisbah kontras | |
| warna paparan | Mono(White) |
| ic pemandu | Built-in KS0066 |
| antara muka isyarat | 8-bit parallel, 16 pins |
| voltan masukan | 3.3V (Typ.) |
