| Nombor Bahagian | WEH001602DR |
| Jenama | Winstar |
| Saiz | 2.3 |
| Permohonan | Instruments & Meters |
| Resolusi | 16×27 |
| Komposisi | PM-OLED , OLED |
| Kecerahan | |
| CR | |
| Warna | Mono(Red) |
| Lampu latar | self |
| Antara muka | |
| jenama panel | Winstar |
| saiz panel | 2.3" |
| format paparan | 16 characters × 2 lines, 7PPI |
| saiz watak | 2.95×5.55(W×H) mm |
| kawasan paparan | 56.95(W)×11.85(H) mm |
| saiz garis besar | 85(W)×30(H) ×10(D) mm |
| sudut pandangan | - |
| pandangan terbaik pada | Symmetry |
| warna paparan | Mono(Red) |
| kekerapan | - |
| berat badan | - |
| model panel | WEH001602DR |
| jenis panel | PM-OLED , OLED |
| format fon | 5×8 dots |
| nada watak | 3.6×6.3(W×H) mm |
| pembukaan bezel | 66(W)×16(H) mm |
| permukaan | - |
| mod paparan | - |
| masa tindak balas | - |
| jenis lampu | self |
| skrin sentuh | Without |
| permohonan | Instruments & Meters |
| AL1602B | Other | 2.3 | 16×2 |
| AMC162A | Other | 2.3 | 16×2 |
| AMC162B | Other | 2.3 | 16×2 |
| DMC-16202NY-LY-BJE-BLN | Kyocera | 2.3 | 16×2 |
| LS023B3UY01 | SHARP | 2.3 | 360×400 |
| TM023KDH60 | Tianma | 2.3 | 320×240 |
