| Nombor Bahagian | WEH001602AL |
| Jenama | Winstar |
| Saiz | 2.3 |
| Permohonan | Instruments & Me |
| Resolusi | 5×8 |
| Komposisi | OLED, PM-OLED |
| Kecerahan | |
| CR | 2000:1 |
| Warna | Mono(Yellow) |
| Lampu latar | self |
| Antara muka | |
| pengilang | Winstar |
| nama model | WEH001602AL |
| saiz skrin | 2.3 inch |
| jenis skrin | OLED, PM-OLED |
| nombor char | 16 characters × 2 lines 7PPI |
| format char | 5×8 dots |
| char pitch(mm) | 3.6×6.3 (H×V) |
| saiz aksara (mm) | 2.95×5.55 (H×V) |
| kawasan aktif (mm) | 56.95 × 11.85 (H×V) |
| garis besar (mm) | 80 × 36 × 10 (H×V×D) |
| kawasan bezel (mm) | 66 × 16 (H×V) |
| rawatan | - |
| kecerahan | - |
| nisbah kontras | 2000 : 1 (Typ.) (TM) |
| sudut pandangan | - |
| tindak balas | 0.01 (Typ.) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | - |
| kedalaman warna | Mono(Yellow) |
| lampu latar | self |
| jisim | - |
| digunakan untuk | Instruments & Meters |
| kadar segar semula | - |
| skrin sentuh | Without |
| - Operating Temp.: -40 ~ 80 °C |
| AL1602B | Other | 2.3 | 16×2 |
| AMC162A | Other | 2.3 | 16×2 |
| AMC162B | Other | 2.3 | 16×2 |
| DMC-16202NY-LY-BJE-BLN | Kyocera | 2.3 | 16×2 |
| LS023B3UY01 | SHARP | 2.3 | 360×400 |
| TM023KDH60 | Tianma | 2.3 | 320×240 |
