| Nombor Bahagian | WEA012864DWPP3N00001 |
| Jenama | Winstar |
| Saiz | 0.96 |
| Permohonan | Instruments & Me |
| Resolusi | 128×64 |
| Komposisi | PM-OLED, OLED |
| Kecerahan | |
| CR | |
| Warna | Mono(White) |
| Lampu latar | self |
| Antara muka | 4-wire |
| jenama | Winstar |
| model | WEA012864DWPP3N00001 |
| saiz pepenjuru | 0.96 inch |
| menaip | PM-OLED, OLED |
| format piksel | 128×64 149PPI |
| konfigurasi | Rectangle |
| kawasan aktif | 21.74(H)×10.86(V) mm |
| garis besar malap. | 38(H)×28.5(V) ×4.37(D) mm |
| kawasan bezel | 23.94(H)×12.06(V) mm |
| rawatan | - |
| arah pandang | Symmetry |
| masa tindak balas | - |
| sudut pandangan | - |
| mod operasi | - |
| warna sokongan | Mono(White) |
| sumber cahaya | self |
| berat badan | - |
| direka untuk | Instruments & Meters |
| kadar bingkai | - |
| panel sentuh | Without |
| perincian d-ic | COG Built-in SSD1306BZ |
| jenis antara muka | 4-wire SPI, I²C , 8 pins PIN |
| bekalan kuasa | 3.3/5.0/7.5V (Typ.) |
| persekitaran | Operating Temperature: -40 ~ 80 °C ; Storage Temperature: -40 ~ 85 °C |
