| Nombor Bahagian | V236BJ1-P02 |
| Jenama | Innolux |
| Saiz | 23.6 |
| Permohonan | LCTV |
| Resolusi | 1366×768 |
| Komposisi | CELL |
| Kecerahan | 0 |
| CR | 3000:1 |
| Warna | 16.7M |
| Lampu latar | No B/L |
| Antara muka | LVDS |
| jenama panel | CHIMEI INNOLUX |
| model panel | V236BJ1-P02 |
| jenis panel | a-Si TFT-LCD , CELL |
| saiz panel | 23.6 inch |
| resolusi | 1366(RGB)×768 , WXGA |
| mod paparan | MVA, Normally Black, Transmissive |
| kawasan aktif | 521.471×293.184 mm |
| garis besar | 535.06×306.34 mm |
| permukaan | Antiglare (Haze 1%), Hard coating (3H) |
| kedalaman kaca | 0.50+0.50 mm |
| ketransmisian | 5.4% (Typ.)(with Polarizer) |
| nisbah kontras | 3000:1 (Typ.) |
| warna paparan | 16.7M (8-bit) |
| masa tindak balas | 8.5 (Typ.)(G to G) |
| sudut pandangan | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| kekerapan | 60Hz |
| antara muka isyarat | LVDS (1 ch, 8-bit), 30 pins |
| voltan masukan | 12.0V (Typ.) |
| permohonan | LCTV |
