BOE HV320WXC-100 lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com
LookLCD LookLCD


HV320WXC-100

HV320WXC-100
HV320WXC-100
HV320WXC-100
HV320WXC-100 thumb HV320WXC-100 thumb HV320WXC-100 thumb
Jenama
BOE
Saiz
31.5
Permohonan
LCTV
Resolusi
1366×768
Komposisi
LCM
Kecerahan
450
CR
1200:1
Warna
16.7M
Lampu latar
CCFL
Antara muka
LVDS
In Stock
9433
Spesifikasi

Nombor Bahagian HV320WXC-100
JenamaBOE
Saiz31.5
PermohonanLCTV
Resolusi1366×768
KomposisiLCM
Kecerahan450
CR1200:1
Warna16.7M
Lampu latarCCFL
Antara mukaLVDS
jenama panelBOE
model panelHV320WXC-100
jenis panel a-Si TFT-LCD , LCM
saiz panel31.5 inch
resolusi1366(RGB)×768 , WXGA
mod paparanADS, Normally Black, Transmissive
kawasan aktif697.685×392.256 mm
garis besar760×450 mm
permukaanAntiglare (Haze 10%), Hard coating (3H)
kecerahan450 cd/m² (Typ.)
nisbah kontras1200:1 (Typ.)
warna paparan16.7M (8-bit), CIE193172%
masa tindak balas8 (Max.)(G to G)
sudut pandangan89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampu4 pcsCCFLEmbedded (Inverter)
antara muka isyaratLVDS (1 ch, 8-bit), 30 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
