Innolux V236BJ1-P01 Rev.C3 lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com
LookLCD LookLCD


V236BJ1-P01 Rev.C3

V236BJ1-P01 Rev.C3
V236BJ1-P01 Rev.C3 thumb
Jenama
Innolux
Saiz
23.6
Permohonan
LCTV
Resolusi
1366×768
Komposisi
CELL
Kecerahan
0
CR
3000:1
Warna
16.7M
Lampu latar
No B/L
Antara muka
LVDS
In Stock
6347
Spesifikasi

Nombor Bahagian V236BJ1-P01 Rev.C3
JenamaInnolux
Saiz23.6
PermohonanLCTV
Resolusi1366×768
KomposisiCELL
Kecerahan0
CR3000:1
Warna16.7M
Lampu latarNo B/L
Antara mukaLVDS
jenama panelCHIMEI INNOLUX
model panelV236BJ1-P01 Rev.C3
jenis panel a-Si TFT-LCD , CELL
saiz panel23.6 inch
resolusi1366(RGB)×768 , WXGA
mod paparanMVA, Normally Black, Transmissive
kawasan aktif521.471×293.184 mm
garis besar535.06×307.34 mm
permukaanAntiglare (Haze 1%), Hard coating (3H)
kedalaman kaca0.50+0.50 mm
ketransmisian5.6% (Typ.)(with Polarizer)
nisbah kontras3000:1 (Typ.)
warna paparan16.7M (8-bit), CIE193172%
masa tindak balas8.5 (Typ.)(G to G)
sudut pandangan88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
kekerapan60Hz
antara muka isyaratLVDS (1 ch, 8-bit), 30 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
