| Nombor Bahagian | M236HJK-L5B |
| Jenama | Innolux |
| Saiz | 23.6 |
| Permohonan | DMPC |
| Resolusi | 1920×1080 |
| Komposisi | LCM |
| Kecerahan | 250 |
| CR | 3000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | INNOLUX |
| model panel | M236HJK-L5B |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 23.6 inch |
| resolusi | 1920(RGB)×1080 , FHD |
| mod paparan | Super MVA, Normally Black, Transmissive |
| kawasan aktif | 521.28×293.22 mm |
| garis besar | 544.68×318.9×16.91 mm |
| permukaan | Hard coating (6H) |
| kecerahan | 250 cd/m² (Typ.) |
| nisbah kontras | 3000:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193172% |
| masa tindak balas | 20/5 (Typ.)(Tr/Td) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | WLEDWithout Driver |
| antara muka isyarat | LVDS (2 ch, 8-bit), 30 pins |
| voltan masukan | 5.0V (Typ.) |
| permohonan | DMPC |
| M236H1-P01 | Innolux | 23.6 | 1920×1080 |
| M236H3-L05 | Innolux | 23.6 | 1920×1080 |
| M236H3-LA3 | Innolux | 23.6 | 1920×1080 |
| M236HGE-L20 | Innolux | 23.6 | 1920×1080 |
| M236HGJ-L11 | Innolux | 23.6 | 1920×1080 |
| M236HGK-L30 | Innolux | 23.6 | 1920×1080 |
| M236HJJ-L30 | Innolux | 23.6 | 1920×1080 |
| M236HJJ-L31 | Innolux | 23.6 | 1920×1080 |
| M236HJK-L3B | Innolux | 23.6 | 1920×1080 |
| M236HJK-L5B | Innolux | 23.6 | 1920×1080 |
| HT170E01-300 | BOE | 17.0 | 1280×1024 |
| LM230WF5-TLC1 | LG Display | 23.0 | 1920×1080 |
| LTM150XH-L01 | Samsung | 15.0 | 1024×768 |
| LTM270DL06 | Samsung | 27.0 | 2560×1440 |
| M185XW01 V3 | AUO | 18.5 | 1366×768 |
| M215H3-LA1 | Innolux | 21.5 | 1920×1080 |
| M240HW02 V1 | AUO | 24.0 | 1920×1080 |
| M240UW01 V0 | AUO | 24.0 | 1920×1200 |
| SVA190WX01TB | SVA-NEC | 19.0 | 1440×900 |
| TD170WGCB2 | TPO | 17.0 | 1280×1024 |
