| Nombor Bahagian | A035VL01 V3 |
| Jenama | AUO |
| Saiz | 3.5 |
| Permohonan | DVC |
| Resolusi | 800×480 |
| Komposisi | LCM |
| Kecerahan | 315 |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | AUO |
| model panel | A035VL01 V3 |
| jenis panel | LTPS TFT-LCD , LCM |
| saiz panel | 3.5 inch |
| resolusi | 800(RGB)×480 , WVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 75.6×45.36 mm |
| garis besar | 86.1×51.66 mm |
| permukaan | Glare (Haze 0%) |
| kecerahan | 315 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) |
| warna paparan | 16.7M (8-bit) |
| masa tindak balas | 15/30 (Typ.)(Tr/Td) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | WLEDWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 8-bit) + SPI, 70 pins |
| voltan masukan | 3.3/3.3V (Typ.)(VDD/VDDIO) |
| permohonan | DVC |
