| Nombor Bahagian | TV101WUB-NV0 |
| Jenama | BOE |
| Saiz | 10.1 |
| Permohonan | Pad & Tablet |
| Resolusi | 1200×1920 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 900:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antara muka | MIPI |
| jenama | BOE |
| model | TV101WUB-NV0 |
| saiz pepenjuru | 10.1 inch |
| menaip | a-Si TFT-LCD, CELL |
| format piksel | 1200(RGB)×1920 [WUXGA] 225PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 135.36(H)×216.576(V) mm |
| garis besar malap. | 140.26(H)×225.346(V) ×0.8(D) mm |
| kecerahan | 0 cd/m² |
| nisbah kontras | 900:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| mod operasi | ADS, Normally Black, Transmissive |
| ketebalan plat | 0.25+0.25 mm |
| penghantaran | 5.1% (Typ.)(with Polarizer) |
| warna sokongan | 16.7M 71% NTSC |
| sumber cahaya | No B/L |
| berat badan | - |
| direka untuk | Pad & Tablet |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| perincian d-ic | COG Built-in 2 source chips |
| jenis antara muka | MIPI (4 data lanes) , 44 pins Connector |
| bekalan kuasa | 3.3/9.8/4.8V (Typ.)(VDDI/AVDD/HAVDD) |
| persekitaran | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
