| Nombor Bahagian | TM070RDSG12 |
| Jenama | TIANMA |
| Saiz | 7.0 |
| Permohonan | Industrial |
| Resolusi | 800×480 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 262K/16.7M |
| Lampu latar | 7S3P |
| Antara muka | |
| pengilang | TIANMA |
| nama model | TM070RDSG12 |
| saiz skrin | 7.0 inch |
| jenis skrin | LCM, a-Si TFT-LCD |
| nombor piksel | 800(RGB)×480 (WVGA) 133PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 152.4 × 91.44 (H×V) |
| garis besar (mm) | 167 × 106.3 × 9.8 (H×V×D) |
| kawasan bezel (mm) | 154.4 × 93.44 (H×V) |
| rawatan | Antiglare |
| kecerahan | 400 cd/m² (Typ.) |
| nisbah kontras | 1000 : 1 (Typ.) (TM) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| tindak balas | 20 (Typ.)(Tr+Td) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | SFT, Normally Black, Transmissive |
| kedalaman warna | 262K/16.7M 70% NTSC |
| lampu latar | 7S3P WLED , 50K hours , With LED Driver |
| jisim | 175g (Typ.) |
| digunakan untuk | Industrial |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
