AUO T420HVN01.1 CELL lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com
LookLCD LookLCD


T420HVN01.1 CELL

T420HVN01.1 CELL
T420HVN01.1 CELL thumb
Jenama
AUO
Saiz
42
Permohonan
LCTV
Resolusi
1920×1080
Komposisi
CELL
Kecerahan
0
CR
3000:1
Warna
16.7M
Lampu latar
No B/L
Antara muka
LVDS
In Stock
12356
Spesifikasi

Nombor Bahagian T420HVN01.1 CELL
JenamaAUO
Saiz42
PermohonanLCTV
Resolusi1920×1080
KomposisiCELL
Kecerahan0
CR3000:1
Warna16.7M
Lampu latarNo B/L
Antara mukaLVDS
jenama panelAUO
model panelT420HVN01.1 CELL
jenis panel a-Si TFT-LCD , CELL
saiz panel42 inch
resolusi1920(RGB)×1080 , FHD
mod paparanAMVA3, Normally Black
kawasan aktif930.24×523.26 mm
garis besar954.24×545.77 mm
permukaanAntiglare (Haze 2%), Hard coating (3H)
kedalaman kaca0.50+0.50 mm
ketransmisian5.7% (Typ.)(with Polarizer)
nisbah kontras3000 : 1 (Typ.)
warna paparan16.7M (8-bit), CIE193172%
masa tindak balas6.5 (Typ.)(G to G)
sudut pandangan89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
antara muka isyaratLVDS (2 ch, 8-bit), 51 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
Model Keluarga
T420HVN01.0 AUO 42 1920×1080
T420HVN01.1 AUO 42 1920×1080
T420HVN01.1 CELL AUO 42 1920×1080
T420HVN02.0 AUO 42 1920×1080
T420HVN02.1 AUO 42 1920×1080
T420HVN04.0 AUO 42 1920×1080
T420HVN04.0 CELL AUO 42 1920×1080
T420HVN05.2 AUO 42 1920×1080
T420HVN06.1 AUO 42 1920×1080
T420HVN08.0 AUO 42 1920×1080
