| Nombor Bahagian | T315XW02 V3 |
| Jenama | AUO |
| Saiz | 31.5 |
| Permohonan | LCTV |
| Resolusi | 1366×768 |
| Komposisi | LCM |
| Kecerahan | 500 |
| CR | 1200:1 |
| Warna | 16.7M |
| Lampu latar | CCFL |
| Antara muka | LVDS |
| jenama panel | AUO |
| model panel | T315XW02 V3 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 31.5 inch |
| resolusi | 1366(RGB)×768 , WXGA |
| mod paparan | AMVA, Normally Black, Transmissive |
| kawasan aktif | 697.68×392.26 mm |
| garis besar | 760×450 mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 500 cd/m² (Typ.) |
| nisbah kontras | 1200:1 (Typ.) |
| warna paparan | 16.7M (8-bit) |
| masa tindak balas | 8 (Typ.)(G to G) |
| sudut pandangan | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | CCFLEmbedded (Inverter) |
| antara muka isyarat | LVDS (1 ch, 8-bit), 30 pins |
| voltan masukan | 5.0V (Typ.) |
| permohonan | LCTV |
| T315XW02 V3 | AUO | 31.5 | 1366×768 |
| T315XW02 VF | AUO | 31.5 | 1366×768 |
| T315XW02 VL | AUO | 31.5 | 1366×768 |
| T315XW02 VM | AUO | 31.5 | 1366×768 |
| T315XW02 VT | AUO | 31.5 | 1366×768 |
| T315XW02 VV | AUO | 31.5 | 1366×768 |
| T315XW03 V3 | AUO | 31.5 | 1366×768 |
| T315XW03 VD | AUO | 31.5 | 1366×768 |
| T315XW03 VF CELL | AUO | 31.5 | 1366×768 |
| T315XW04 V1 | AUO | 31.5 | 1366×768 |
| LC320WXN-SCA1 | LG Display | 31.5 | 1366×768 |
| LC370WUN-SBA1 | LG Display | 37 | 1920×1080 |
| LC420EUN-FEF1 | LG Display | 42 | 1920×1080 |
| LC550EUN-SEM1 | LG Display | 55 | 1920×1080 |
| T315XW03 V4 | AUO | 31.5 | 1366×768 |
| T420HW09 V2 | AUO | 42 | 1920×1080 |
| T460HB01 V0 | AUO | 46 | 1920×1080 |
| V236BJ1-LE1 | Innolux | 23.6 | 1366×768 |
| V420H1-L15 | Innolux | 42 | 1920×1080 |
| V580DK2-QS1 | Innolux | 58 | 3840×2160 |
