| Nombor Bahagian | S035LQNC111 |
| Jenama | CDTECH |
| Saiz | 3.5 |
| Permohonan | Automotive Display I |
| Resolusi | 320×240 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 350:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | Parallel |
| jenama | CDTECH |
| saiz pepenjuru | 3.5 inch |
| format piksel | 320(RGB)×240 [QVGA] 115PPI |
| kawasan aktif | 70.08(H)×52.56(V) mm |
| kawasan bezel | 71.3(H)×55.5(V) mm |
| kecerahan | 350 cd/m² (Typ.) |
| arah pandang | 12 o'clock |
| sudut pandangan | 65/65/65/55 (Typ.)(CR≥10) |
| warna sokongan | 16.7M 50% NTSC |
| berat badan | TBD |
| kadar bingkai | 60Hz |
| jenis antara muka | Parallel RGB (1 ch, 8-bit) + SPI , 54 pins FPC |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| model | S035LQNC111 2 Compatible |
| menaip | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar malap. | 76.9(H)×63.9(V) ×3.46(D) mm |
| rawatan | Hard coating |
| nisbah kontras | 350:1 (Typ.) (TM) |
| masa tindak balas | 25/25 (Typ.)(Tr/Td) |
| mod operasi | TN, Normally White, Transmissive |
| sumber cahaya | WLED [6S1P] , 25K hours , W/O Driver |
| direka untuk | Automotive Display Industrial Handheld & PDA |
| panel sentuh | Without |
