| Nombor Bahagian | UMSH-8065MD-11T |
| Jenama | Other |
| Saiz | 3.5 |
| Permohonan | IA |
| Resolusi | 320×240 |
| Komposisi | LCM |
| Kecerahan | 700 |
| CR | 800:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | Parallel/Serial |
| jenama panel | URT |
| model panel | UMSH-8065MD-11T |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 3.5 inch |
| resolusi | 320(RGB)×240 , QVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 70.08×52.56 mm |
| garis besar | 76.9×63.9×3.5 mm |
| permukaan | |
| kecerahan | 700 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 15/35 (Typ.)(Tr/Td) |
| sudut pandangan | 80/80/45/80 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 70Hz |
| jenis lampu | 5S2PWLEDWithout Driver |
| antara muka isyarat | Digital RGB (8/24-bit) + SPI, CCIR601/656, 50 pins |
| voltan masukan | 3.3/3.3V (Typ.)(VCI/VDDIO) |
| permohonan | IA |
| EL160.80.50 ET CC | Lumineq | 3.5 | 160×80 |
| LB035Q04-TD08 | LG Display | 3.5 | 320×240 |
| LH350WV3-SH01 | LG Display | 3.5 | 480×854 |
| LMS350DF03 | Samsung | 3.5 | 320×480 |
| LQ035Q7DB02R | SHARP | 3.5 | 240×320 |
| LTV035QV-F09 | Samsung | 3.5 | 320×240 |
| PT035TN01 V.3 | Innolux | 3.5 | 320×240 |
| TCG035QVLPDANN-GN50 | Kyocera | 3.5 | 320×240 |
| TX09D40VM3CBA | KOE | 3.5 | 240×320 |
| UMSH-8065MD-11T | Other | 3.5 | 320×240 |
| AA121SL07 | Mitsubishi | 12.1 | 800×600 |
| AA121SL09 | Mitsubishi | 12.1 | 800×600 |
| AA190EA01 | Mitsubishi | 19.0 | 1280×1024 |
| COM57H5M10XRC | ORTUSTECH | 5.7 | 640×480 |
| G133IGE-L03 | Innolux | 13.3 | 1280×800 |
| LM32019T | SHARP | 5.7 | 320×240 |
| NL10276BC24-19D | NLT | 12.1 | 1024×768 |
| NL10276BC30-38B | NLT | 15.0 | 1024×768 |
| T-51639D084JU-FW-A-AB | Kyocera | 8.4 | 1024×768 |
| UG-2832TSWGG01 | WiseChip | 1.0 | 128×32 |
