| Nombor Bahagian | PA080XS2 |
| Jenama | E Ink |
| Saiz | 7.9 |
| Permohonan | CNS |
| Resolusi | 480×468 |
| Komposisi | LCM |
| Kecerahan | 350 |
| CR | 350:1 |
| Warna | Full color |
| Lampu latar | CCFL |
| Antara muka | Analog |
| jenama panel | PVI |
| model panel | PA080XS2 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 7.9 inch |
| resolusi | 480(RGB)×468 |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 161.28×117.936 mm |
| garis besar | 172.4×132×6.9 mm |
| permukaan | Antiglare |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 350:1 (Typ.) |
| warna paparan | Full color |
| masa tindak balas | 15/25 (Typ.)(Tr/Td) |
| sudut pandangan | 60/60/40/50 (Typ.)(CR≥10)(L/R/U/D) |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | TFT Specific Analog RGB, 32 pins |
| voltan masukan | 3.3/3.3/13.0/24.0/-8.0V (Typ.)(VCC/VDD1/VDD2/VGH/VEE) |
| permohonan | CNS |
