| Nombor Bahagian | PA050XSG |
| Jenama | E Ink |
| Saiz | 5.0 |
| Permohonan | CNS |
| Resolusi | 320×234 |
| Komposisi | LCM |
| Kecerahan | 400 |
| CR | 400:1 |
| Warna | |
| Lampu latar | CCFL |
| Antara muka | Analog |
| jenama panel | PVI |
| model panel | PA050XSG |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 5.0 inch |
| resolusi | 320(RGB)×234 |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 102.72×74.53 mm |
| garis besar | 119.3×91.4×7.8 mm |
| permukaan | Antiglare |
| kecerahan | 400 cd/m² (Typ.) |
| nisbah kontras | 400:1 (Typ.) |
| warna paparan | |
| masa tindak balas | 15/30 (Typ.)(Tr/Td) |
| sudut pandangan | 70/70/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | TFT Specific Analog RGB, 30 pins |
| voltan masukan | 3.3/3.3/5.0/17.0/-12.0V (Typ.)(VCC/VDD1/VDD2/VGH/VGL) |
| permohonan | CNS |
