| Nombor Bahagian | N080XCG-L21 |
| Jenama | Innolux |
| Saiz | 8.0 |
| Permohonan | |
| Resolusi | 1024×768 |
| Komposisi | LCM |
| Kecerahan | 400 |
| CR | 800:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | CHIMEI INNOLUX |
| model panel | N080XCG-L21 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 8.0 inch |
| resolusi | 1024(RGB)×768 , XGA |
| mod paparan | IPS, Normally Black, Transmissive |
| kawasan aktif | 162.048×121.536 mm |
| garis besar | 183×141×2.9 mm |
| permukaan | Glare (Haze 0%), Hard coating (3H) |
| kecerahan | 400 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) |
| warna paparan | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193150% |
| masa tindak balas | 13/12 (Typ.)(Tr/Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | WLEDWithout Driver |
| antara muka isyarat | LVDS (1 ch, 6/8-bit), 40 pins |
| voltan masukan | 3.3/10.6V (Typ.)(VDD/AVDD) |
