| Nombor Bahagian | TD036THEA3 |
| Jenama | TPO |
| Saiz | 3.6 |
| Permohonan | |
| Resolusi | 320×240 |
| Komposisi | LCM |
| Kecerahan | 280 |
| CR | 400:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | Serial RGB |
| jenama panel | Toppoly |
| model panel | TD036THEA3 |
| jenis panel | LTPS TFT-LCD , LCM |
| saiz panel | 3.6 inch |
| resolusi | 320(RGB)×240 , QVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 72.96×54.72 mm |
| garis besar | 80.2×66.3 mm |
| permukaan | Hard coating (3H) |
| kecerahan | 280 cd/m² (Typ.) |
| nisbah kontras | 400:1 (Typ.) |
| warna paparan | 16.7M (8-bit) |
| masa tindak balas | 13/22 (Typ.)(Tr/Td) |
| sudut pandangan | 50/20/40/40 (Typ.)(CR≥10)(L/R/U/D) |
| jenis lampu | 3S2PWLED |
| antara muka isyarat | Serial RGB (8-bit) + SPI, CCIR601, 40 pins |
| voltan masukan | 3.0V (Typ.)(VCC) |
