| Nombor Bahagian | N070Y1-T01 |
| Jenama | Innolux |
| Saiz | 7.0 |
| Permohonan | UMPC |
| Resolusi | 800×480 |
| Komposisi | LCM |
| Kecerahan | 250 |
| CR | 400:1 |
| Warna | 262K |
| Lampu latar | CCFL |
| Antara muka | TTL |
| jenama panel | CMO |
| model panel | N070Y1-T01 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 7.0 inch |
| resolusi | 800(RGB)×480 , WVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 152.4×91.44 mm |
| garis besar | 165×104×5.8 mm |
| permukaan | Antiglare |
| kecerahan | 250 cd/m² (Typ.) |
| nisbah kontras | 400:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 5/11 (Typ.)(Tr/Td) |
| sudut pandangan | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 6-bit), 40 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | UMPC |
| AM-1024600KTMQW-01H | AMPIRE | 7.0 | 1024×600 |
| B070EAN01.6 | AUO | 7.0 | 800×1280 |
| CLAA070NB02CT | CPT | 7.0 | 1024×600 |
| EJ070IA-04A | Innolux | 7.0 | 800×1280 |
| FG0700G3DSSWBGL4 | Data Image | 7.0 | 800×480 |
| LA070WV6-SD01 | LG Display | 7.0 | 800×480 |
| LD070WX5-SM01 | LG Display | 7.0 | 900×1440 |
| LMS700KF06 | Samsung | 7.0 | 800×480 |
| LQ070Y3LW01 | SHARP | 7.0 | 800×480 |
| N070Y1-T01 | Innolux | 7.0 | 800×480 |
| CLAA080UA01 | CPT | 8.0 | 1600×768 |
| HSD070PWW1-C00 | HannStar | 7.0 | 1280×800 |
| LD050WV1-SP01 | LG Display | 5.0 | 480×800 |
| LD070WS2-SL05 | LG Display | 7.0 | 1024×600 |
| LD070WS2-SL07 | LG Display | 7.0 | 1024×600 |
| LTD056ET0T | TOSHIBA | 5.6 | 1024×600 |
| LTD056ET2F | TOSHIBA | 5.6 | 1024×600 |
| LTD056EV7F00 | TOSHIBA | 5.6 | 1280×800 |
| N070ICG-LD1 | Innolux | 7.0 | 1280×800 |
| N070ICG-LD4 | Innolux | 7.0 | 1280×800 |
