| Nombor Bahagian | M090AWP4 R1 |
| Jenama | IVO |
| Saiz | 9.0 |
| Permohonan | Outdoor High Brightn |
| Resolusi | 800×480 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 700:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | Parallel |
| pengilang | IVO |
| saiz skrin | 9.0 inch |
| nombor piksel | 800(RGB)×480 (WVGA) 104PPI |
| kawasan aktif (mm) | 198 × 112.08 (H×V) |
| kawasan bezel (mm) | 200.2 × 114.28 (H×V) |
| kecerahan | 750 cd/m² (Typ.) |
| sudut pandangan | 70/70/50/70 (Typ.)(CR≥10) |
| pandangan yang baik di | 6 o'clock |
| kedalaman warna | 262K 70% NTSC |
| jisim | - |
| kadar segar semula | 60Hz |
| jenis isyarat | Parallel RGB (1 ch, 6-bit) , 60 pins FPC |
| maks. penilaian | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C |
| nama model | M090AWP4 R1 |
| jenis skrin | LCM , a-Si TFT-LCD |
| susunan | RGB Vertical Stripe |
| garis besar (mm) | 210.82 × 126.96 × 6.4 (H×V×D) |
| rawatan | Antiglare, Hard coating (3H) |
| nisbah kontras | 700 : 1 (Typ.) (TM) |
| tindak balas | 12 (Typ.)(Tr+Td) ms |
| mod kerja | TN, Normally White, Transmissive |
| lampu latar | WLED , No Driver |
| digunakan untuk | Outdoor High Brightness Automotive Display |
| skrin sentuh | Without |
