| Nombor Bahagian | LQ070Y5DG30 |
| Jenama | SHARP |
| Saiz | 7.0 |
| Permohonan | CNS |
| Resolusi | 800×480 |
| Komposisi | LCM |
| Kecerahan | |
| CR | |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | SHARP |
| model panel | LQ070Y5DG30 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 7.0 inch |
| resolusi | 800(RGB)×480 , WVGA |
| mod paparan | |
| kawasan aktif | 156.4×82.08 mm |
| garis besar | 166×93.2 mm |
| permukaan | |
| kecerahan | |
| nisbah kontras | |
| warna paparan | 262K (6-bit) |
| masa tindak balas | |
| sudut pandangan | |
| jenis lampu | WLED |
| antara muka isyarat | Parallel RGB (1 ch, 6-bit) |
| permohonan | CNS |
