| Nombor Bahagian | LQ070Y3DG02 |
| Jenama | SHARP |
| Saiz | 7.0 |
| Permohonan | DPF |
| Resolusi | 800×480 |
| Komposisi | LCM |
| Kecerahan | 280 |
| CR | 450:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | SHARP |
| model panel | LQ070Y3DG02 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 7.0 inch |
| resolusi | 800×480(RGB) , WVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 152.4×91.44 mm |
| garis besar | 164.9×104×5.3 mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 280 cd/m² (Typ.) |
| nisbah kontras | 450:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193148% |
| masa tindak balas | 35 (Typ.)(Tr+Td) |
| sudut pandangan | 65/65/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 8S3PWLEDWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 8-bit), 51 pins |
| voltan masukan | 1.8/2.85V (Typ.)(VDDIO/VCI) |
| permohonan | DPF |
| LQ070T3AG02 | SHARP | 7.0 | 480×234 |
| LQ070T5AR01 | SHARP | 7.0 | 480×234 |
| LQ070T5DG30 | SHARP | 7.0 | |
| LQ070T5DR06 | SHARP | 7.0 | 480×240 |
| LQ070Y3DG04 | SHARP | 7.0 | 800×480 |
| LQ070Y3DG3A | SHARP | 7.0 | 800×480 |
| LQ070Y3LG05 | SHARP | 7.0 | 800×480 |
| LQ070Y3LG4A | SHARP | 7.0 | 800×480 |
| LQ070Y5DA02A | SHARP | 7.0 | 800×480 |
| LQ070Y5DG01 | SHARP | 7.0 | 800×480 |
| AT070TN01 | Innolux | 7.0 | 480×234 |
| AT070TN90 | Innolux | 7.0 | 800×480 |
| AT080TN03 V.7 | Innolux | 8.0 | 800×480 |
| AT090TN12 V.3 | Innolux | 9.0 | 800×480 |
| HSD090ICW1-A00 | HannStar | 9.0 | 640×234 |
| HSD101PFW3-D00 | HannStar | 10.1 | 1024×600 |
| LSA40AT9001 | Innolux | 10.4 | 800×600 |
| LTE700WQ-F05 | Samsung | 7.0 | 480×234 |
| LW700AT9901 | Innolux | 7.0 | 800×480 |
| TM070RDH13 | Tianma | 7.0 | 800×480 |
