| Nombor Bahagian | LQ055W1GC01 |
| Jenama | SHARP |
| Saiz | 5.5 |
| Permohonan | UMPC |
| Resolusi | 1024×600 |
| Komposisi | LCM |
| Kecerahan | 200 |
| CR | 300:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | Mini LVDS |
| jenama panel | SHARP |
| model panel | LQ055W1GC01 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 5.5 inch |
| resolusi | 1024(RGB)×600 , WSVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 119.808×70.2 mm |
| garis besar | 130.2×81.15 mm |
| permukaan | Clear, Hard coating (2H) |
| kecerahan | 200 cd/m² (Typ.) |
| nisbah kontras | 300:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| sudut pandangan | 60/50/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 8S1PWLEDWithout Driver |
| antara muka isyarat | Mini LVDS, 40 pins |
| voltan masukan | 2.5/7.9V (Typ.)(VCC/VDD) |
| permohonan | UMPC |
| CLAA070NP01 | CPT | 7.0 | 1024×600 |
| HSD070PWW1-B01 | HannStar | 7.0 | 1280×800 |
| HV056WX1-100 | HYDIS | 5.6 | 1280×800 |
| HV056WX1-101 | HYDIS | 5.6 | 1280×800 |
| LB048WV1-TL01 | LG Display | 4.8 | 800×480 |
| LD070WS2-SL01 | LG Display | 7.0 | 1024×600 |
| LD070WS2-SL06 | LG Display | 7.0 | 1024×600 |
| LTD056EV7F00 | TOSHIBA | 5.6 | 1280×800 |
| N070ICG-LD1 | Innolux | 7.0 | 1280×800 |
| N070Y1-T01 | Innolux | 7.0 | 800×480 |
