| Nombor Bahagian | LB048WV1-TL01 |
| Jenama | LG Display |
| Saiz | 4.8 |
| Permohonan | UMPC |
| Resolusi | 800×480 |
| Komposisi | LCM |
| Kecerahan | 280 |
| CR | 350:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | LG.Philips LCD |
| model panel | LB048WV1-TL01 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 4.8 inch |
| resolusi | 800(RGB)×480 , WVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 103.8×62.28 mm |
| garis besar | 114.65×74.7×5.88 mm |
| permukaan | Glare (Haze 0%), Hard coating (3H) |
| kecerahan | 280 cd/m² (Typ.) |
| nisbah kontras | 350:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 16 (Typ.)(Tr+Td) |
| sudut pandangan | 65/65/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 6S2PWLEDEmbedded (LED Driver) |
| antara muka isyarat | LVDS (1 ch, 6-bit), 30 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | UMPC |
