| Nombor Bahagian | LQ043T1DH42 |
| Jenama | SHARP |
| Saiz | 4.3 |
| Permohonan | PND |
| Resolusi | 480×272 |
| Komposisi | LCM |
| Kecerahan | 360 |
| CR | 300:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | SHARP |
| model panel | LQ043T1DH42 2 Compatible model |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 4.3 inch |
| resolusi | 480×272(RGB) , WQVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 95.04×53.856 mm |
| garis besar | 105.5×67.2×4.45 mm |
| permukaan | Antiglare, Hard coating (2H) |
| kecerahan | 360 cd/m² (Typ.) |
| nisbah kontras | 300:1 (Typ.) |
| warna paparan | 262K (6-bit), CIE193148% |
| masa tindak balas | 8/8 (Typ.)(Tr/Td) |
| sudut pandangan | 45/45/20/55 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 9S1PWLEDWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 6-bit) + SPI, 67 pins |
| voltan masukan | 1.8/(3.3/2.8)V (Typ.)(VDDIO/VCI) |
| permohonan | PND |
