| Nombor Bahagian | HV056WX2-100 |
| Jenama | HYDIS |
| Saiz | 5.6 |
| Permohonan | UMPC |
| Resolusi | 1280×800 |
| Komposisi | Assembly |
| Kecerahan | 220 |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | HYDIS |
| model panel | HV056WX2-100 |
| jenis panel | a-Si TFT-LCD , Assembly |
| saiz panel | 5.6 inch |
| resolusi | 1280(RGB)×800 , WXGA |
| kawasan aktif | 120.96×75.6 mm |
| garis besar | 158×90.3 mm |
| permukaan | Glare (Haze 0%), Hard coating (2H) |
| kecerahan | 220 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Typ.) |
| warna paparan | 262K (6-bit), CIE193145% |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| antara muka isyarat | LVDS (1 ch, 6-bit), 25 pins |
| permohonan | UMPC |
