| Nombor Bahagian | KCB6448BSTT-X4 |
| Jenama | Kyocera |
| Saiz | 10.4 |
| Permohonan | IA |
| Resolusi | 640×480 |
| Komposisi | LCM |
| Kecerahan | |
| CR | 20:1 |
| Warna | Color |
| Lampu latar | CCFL |
| Antara muka | Parallel Data |
| jenama panel | Kyocera |
| model panel | KCB6448BSTT-X4 |
| jenis panel | CSTN-LCD , LCM |
| saiz panel | 10.4 inch |
| resolusi | 640(RGB)×480 , VGA |
| mod paparan | STN, Normally Black, Transmissive |
| kawasan aktif | 211.2×158.4 mm |
| permukaan | |
| kecerahan | |
| nisbah kontras | 20:1 (Typ.) |
| warna paparan | Color , CIE193140% |
| masa tindak balas | 160/80 (Typ.)(Tr/Td) |
| sudut pandangan | |
| kekerapan | 75Hz |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | Parallel Data (2ch, 8-bit) |
| voltan masukan | 5.0V (Typ.) |
| permohonan | IA |
