| Nombor Bahagian | LQ092B5DW02 |
| Jenama | SHARP |
| Saiz | 9.2 |
| Permohonan | IA |
| Resolusi | 960×160 |
| Komposisi | LCM |
| Kecerahan | 1050 |
| CR | 1000:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | SHARP |
| model panel | LQ092B5DW02 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 9.2 inch |
| resolusi | 960(RGB)×160 |
| mod paparan | ASV, Normally Black, Transmissive |
| kawasan aktif | 230.4×38.4 mm |
| garis besar | 242×52.83×10.8 mm |
| permukaan | Antiglare |
| kecerahan | 1050 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 8/6 (Typ.)(Tr/Td) |
| sudut pandangan | |
| kekerapan | 60Hz |
| jenis lampu | 6S4PWLEDWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 6-bit), 50 pins |
| voltan masukan | 3.3/13.4/25.0/-8.0V (Typ.)(VSHD/VSHA/VGH/VGL) |
| permohonan | IA |
