| Nombor Bahagian | HV121X02-100 |
| Jenama | HYDIS |
| Saiz | 12.1 |
| Permohonan | IA |
| Resolusi | 1024×768 |
| Komposisi | CELL |
| Kecerahan | 0 |
| CR | 450:1 |
| Warna | 262K |
| Lampu latar | No B/L |
| Antara muka | LVDS |
| jenama panel | BOE HYDIS |
| model panel | HV121X02-100 |
| jenis panel | a-Si TFT-LCD , CELL |
| saiz panel | 12.1 inch |
| resolusi | 1024(RGB)×768 , XGA |
| mod paparan | AFFS, Normally Black, Transmissive |
| kawasan aktif | 245.76×184.32 mm |
| permukaan | Glare (Haze 0%), Antireflection |
| ketransmisian | 5.91% (Typ.)(with Polarizer) |
| nisbah kontras | 450:1 (Typ.) |
| warna paparan | 262K (6-bit), CIE193140% |
| masa tindak balas | 32 (Typ.)(Tr+Td) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| antara muka isyarat | LVDS (1 ch, 6-bit), 20 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | IA |
