| Nombor Bahagian | HSD050FMW2-D00 |
| Jenama | HannStar |
| Saiz | 5.0 |
| Permohonan | MPH |
| Resolusi | 540×960 |
| Komposisi | CELL |
| Kecerahan | 0 |
| CR | 700:1 |
| Warna | 16.7M |
| Lampu latar | No B/L |
| Antara muka | |
| jenama panel | HannStar |
| model panel | HSD050FMW2-D00 2 Compatible model |
| jenis panel | a-Si TFT-LCD , CELL |
| saiz panel | 5.0 inch |
| resolusi | 540(RGB)×960 , qHD |
| mod paparan | IPS Pro, Normally Black, Transmissive |
| kawasan aktif | 62.046×110.304 mm |
| garis besar | 65.1×117.9×0.4 mm |
| permukaan | Without Polarizer |
| kedalaman kaca | 0.20+0.20 mm |
| ketransmisian | 3.82% (Typ.)(with Polarizer) |
| nisbah kontras | 700:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193172% |
| masa tindak balas | 10/20 (Typ.)(Tr/Td) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| ic pemandu | COG Suggest NT35516, NT35517, HX8389-B, RM68190, OTM9608A, OTM9605A |
| permohonan | MPH |
| ACX534AKM-2 | SONY | 5.0 | 800×600 |
| AT050TN23 V.1 | Innolux | 5.0 | 640×480 |
| HSD050FMW2-D00 | HannStar | 5.0 | 540×960 |
| LS050T1SX06 | SHARP | 5.0 | 1080×1920 |
| LTE052T-4301-1 | TPO | 5.0 | 320×234 |
| P50AD2 | E Ink | 5.0 | 320×234 |
| PA050DS2T1 | E Ink | 5.0 | 320×234 |
| PA050XS1 | E Ink | 5.0 | 320×234 |
| TM050QDH11 | Tianma | 5.0 | 640×480 |
| TY05001C0-40 V1 | Other | 5.0 | 800×480 |
| ET0320A5DM9 | EDT | 3.2 | 240×320 |
| H429AL02.0 | AUO | 4.3 | 540×960 |
| HVA42WV1-M00 | HYDIS | 4.2 | 480×800 |
| LH480HX1-SD01 | LG Display | 4.8 | 480×1024 |
| LM18WGSBZ05 | SHARP | 1.8 | 120×160 |
| LS022Q8UD04 | SHARP | 2.2 | 240×320 |
| LS050T1SX12(K) | SHARP | 5.0 | 1080×1920 |
| LS055R1SX03 | SHARP | 5.5 | 1440×2560 |
| LT032MDQ7000 | JDI | 3.2 | 360×480 |
| TM045YDH27 | Tianma | 4.5 | 480×854 |
